Pick-up / �� 7.5T

PHOENIX

Big on performance. Big on comfort.

GVW

3,500 kg

Power

80 hp @ 3,300 rpm

Payload

2 t

Enquire about PHOENIX Financing Talk to sales

5 yr / 500,000 km

Trucks · Pick-up / �� 7.5T

In the field

See the PHOENIX at work

Application 1 / 15

Bakeries

Why it wins

Built-in highlights

Big on performance
Low fuel consumption
Big on comfort
Euro 4 compliant

Payload

2 t

9.5 ft

Full specifications

Explore every detail

Wheelbase

2,590 mm

Drive type

4x2

Engine

1.5L, 3 Cylinder Diesel

Engine power

80 hp @ 3,300 rpm

Engine torque

190 Nm @ 1,600 2,400 rpm

Clutch

240 mm single diaphragm push type cable

Gearbox

Fully synchronised 5-speed manual

Front axle

Forged I-section reversed Elliot

Rear axle

Fully-floating single-speed hypoid (RAR 4.33)

Tyre

215/75 R15 LT (Tubeless)

Front suspension

2-stage overslung parabolic (3 leaves)

Rear suspension

2-stage semi-elliptic (3 main + 3 helper)

Steering

Power assisted, tiltable column

BakeriesSupermarketsPick-up marketGroceriesCleaning companiesHotelsLight logisticsEgg suppliersBeverage distributionMeat suppliersGas deliveriesPharmaceuticalsHardware deliveriesGlass deliveryElectronics

5 yr / 500,000 km warranty · Assembled at AVA plant, Mombasa · *T&Cs apply
